DWT 18000 HD
Commercial & Utility vehicles
Emergency & defense
Voltage: 24V
Motor: 9 HP
Pulling rate: 18000 lb/ 8165 kg
Gear train: 3 stage planetary
Reduction rotio: 358:1
Brake: dynamic
Length of the steel cable: 30 m
Length of the synthetic rope: 21 m
Weight: 63 kg
Mounting bolt patern: 254 mm x 114 mm
Overall product dimensions (LxWxH): 586 mm x 196 mm x 265 mm
DESIGNED AND ENGINEERED IN THE POLAND
Set components
Technical parameters
DOWNLOAD THE MANUAL
DOWNLOAD
CABLE WINDING SPEED AND POWER CONSUMPTION
(THE FIRST CABLE LAYER ON THE DRUM)
(THE FIRST CABLE LAYER ON THE DRUM)
| CABLE LOAD | kg | - | 2721 | 5443 | 8165 |
| CABLE SPEED | m/min | 5,5 | 4,1 | 3,1 | 1,5 |
| POWER CONSUMPTION 24 V | amp | 39 | 105 | 214 | 280 |
PULLING FORCE DEPENDING ON CABLE LAYER
| CABLE LAYER | 1 | 2 | 3 | 4 | 5 | |
| CABLE PULL | kg | 8165 | 6450 | 5552 | 4817 | 4001 |
| CABLE LENGTH ON THE DRUM | m | 5,2 | 11,4 | 19,0 | 27,8 | 30,0 |
